CHAPTER 5
44 ISOBUS Product Control Installation & Operation Manual
INJECTION PUMP STATUS BUTTON
If a Raven Sidekick Pro ISO injection pump is connected to the product control system, the Product Control Home
screen will display a pump status button for each detected pump (maximum of three pumps) on this screen.
Touch this button to toggle the selected ISO injection pump on or off.
SECTION STATUS DISPLAY
Below the tank volume display, the status of each configured section is displayed.
NOTE: Refer to the Implement Calibration Tab section on page 15 to configure sections.
Manually disabled sections are displayed without a triangle below the section. See the On-Screen Manual Section
Controls section on page 45 for using manual section controls.
Sections
On
