Manual No. 016-0171-362 Rev. F 39
ISOBUS PRODUCT CONTROL OPERATION
FAN SWITCH OR BOOST PUMP STATUS
If a dry or granular product type is selected, a fan switch status indicator will be available in the quick access
softkeys area. Select this indicator to toggle the fan switch on or off.
If the NH3 Applicator product control type is selected, a boost pump status indicator will be available in the quick
access softkeys area. Select this indicator to toggle the AccuFlow HP boost pump on or off. Refer to the AccuFlow
and AccuFlow HP Installation and Operation Manual for details on operating the boost pump.
NOTE: The fan switch or boost pump switch status indicator must be toggled on or off manually. The fan or
pump will not be toggled automatically when the master or remote master switch is operated.
REMOTE MASTER STATUS
The current status of the remote master is shown in the top, center of the display. To toggle the remote master,
press the foot switch.
NOTE: Both the remote master (foot switch) and the master switch must be toggled on to apply product.
CONTROL MODE (AUTO/MANUAL)
The control mode indicator displays the selected mode for product application. Select the “Auto/Manual” button
to toggle the application mode between automatic and manual. The active mode displays green in the control
mode display area.
• Manual mode allows the operator to control the actual application rate directly using the on-screen increase
and decrease buttons.
• In automatic mode, the product control system automatically adjusts the application rate to an operator set
target rate. Using the rate increase or decrease buttons in auto mode adjusts the target application rate.
APPLICATION SPEED
The current vehicle speed is displayed on the product control home screen.
