Raven ISOBUS Product Control User Manual

CHAPTER 2
6 ISOBUS Product Control Installation & Operation Manual
TABLE 3. ISOBUS Single Product (Liquid/Granular) Node Kit
(37-Pin Product Cable) (P/N 117-6100-002)
NOTE: A 21’ spinner control cable (P/N 115-0171-880) is required if the ISOBUS product control system will be
utilized for spinner control applications.
TABLE 5. ISOBUS Single Product (Liquid/Granular) Node Kit
(22-Pin Product Cable) (P/N 117-6100-003)
NOTE: A 21’ spinner control cable (P/N 115-0171-880) is required if the ISOBUS product control system will be
utilized for spinner control applications.
UPDATES
Updates for Raven manuals as well as software updates for Raven consoles are available at the Applied Technology
Division web site:
www.ravenhelp.com
TABLE 4.
Description Part Number Qty.
Terminator, Active CAN Powell 063-0172-964 1
Node, ISOBUS Single Product 063-0173-006 1
Switch, ISO Node Foot 063-0173-080 1
Cable, Main Node 115-0171-945 1
Cable, Cab Foot Switch, 8’ 115-0171-865 1
Cable, ISO Powell Terminator Adapter 115-0171-963 1
TABLE 6.
Description Part Number Qty.
Terminator, Active CAN Powell 063-0172-964 1
Node, ISOBUS Single Product 063-0173-006 1
Switch, ISO Node Foot 063-0173-080 1
Cable, 37-pin to 22-pin Adapter 115-0171-864 1
Cable, Main Node 115-0171-945 1
Cable, Cab Foot Switch, 8’ 115-0171-865 1
Cable, ISO Powell Terminator Adapter 115-0171-963 1

Raven ISOBUS Product Control Specifications

General

Brand	Raven
Model	ISOBUS Product Control
Category	Control Unit
Language	English
