CHAPTER 5
40 ISOBUS Product Control Installation & Operation Manual
PUMP RPM CAL (SPRAY APPLICATOR)
The current pump RPM is displayed in this area when a Pump RPM Cal value is entered. Refer to Pump RPM Cal
section on page 20 to set the Pump RPM Cal value.
PRODUCT DENSITY (GRANULAR APPLICATIONS)
Select the density value to enter the product density of the product being applied. For best results, make sure to
keep this value updated as the density of the product changes.
TARGET PRESSURE (NH3 APPLICATIONS)
The currently set target pressure for the NH3 boost pump displays in this area. Refer to the Pressure or Spinner/
Fan RPM Display section below for details on changing the boost pump target pressure.
