Manual No. 016-0171-362 Rev. F 63
VALVE CAL 2
NOTE: If the dual loop control feature is enabled, the valve cal 2 value will be replaced by the Sgain (pressure
system gain) value.
When a fast close valve is selected, the valve cal 2 value is utilized to enable a high resolution rate control for lower
application rates.
Enter a non-zero value for the time, in milliseconds, which the valve will be fully opened before switching into high
resolution control. For example, a value of 200 will give the valve a 200 millisecond “burst” at a full 12V to open the
fast valve from the closed position before resuming product rate control. A zero value will disable this feature.
FLOW CAL (DUAL LOOP CONTROL MODE)
The flow cal value has two components which may be used to adjust the response of the application system.
NOTE: It is recommended to set the Sgain value prior to making any adjustments to the flow cal value.
Flow System Gain. The first digit(s) of the flow cal correspond to a flow system gain between 1 and 99. The higher
the flow system gain, the more aggressive the system will respond to changes in flow rate.
NOTE: When entering a flow gain value from 1 to 9, it is not necessary to enter a zero in front of the value.
If the system adjusts to rate control changes too slowly, increase the flow gain digit(s) to increase the system
response rate. If the system overshoots or oscillates around the desired flow rate, decrease the flow gain digit(s) to
help stabilize the system.
Dead Band Digit. The last, or right most, digit in the flow cal value is the dead band digit. The dead band digit is
the allowable difference between the target rate and the actual application rate. The values range from 1 to 9,
where 1 equals 1% difference and 9 equals 9% of the difference.
SGAIN (PRESSURE SYSTEM GAIN - DUAL LOOP CONTROL MODE)
The default setting for the Sgain value is 100. To adjust the system aggressiveness, enter a value between 1 and
999 as necessary.
NOTE: It is recommended to increase or decrease the current value in increments of 10 or less when making
adjustments to the Sgain setting. If the new value does not produce significant or notable changes in
the system response, increments of 20 may be used.
Increase the Sgain value if the observed product pressure increases too slowly or if the system takes a long time to
reach a set standby pressure or rate input change. If the system is consistently over shooting a set standby
pressure or oscillating around a target rate, decrease the Sgain value until the system stabilizes.
Flow System
Dead
Band
103
