-46 C-Series Displays Installation Manual
Inserting a card
To insert a card, refer to the illustration, and:
1. Check that you are using the correct type of card.
See “Electronic Cards” on
page 9.
2. Open the chart card door, located on the front left of the display.
3. Insert the card as shown, with the lip of the card facing inwards, it should position
easily. If it does not, DO NOT force it, check the direction in which the lip is facing.
4. Gently press the card home.
5. To prevent the ingress of water and consequent damage, close the chart card door
and press firmly until an audible click is heard.
D6517-1
Narrow
Groove
Lip
To Next Page
