SET-UP & BASIC OPERATION
18
SET-UP & BASIC OPERATION
The OSCOR is a stand-alone spectrum analyzer with a built-in antenna panel ready to be used right out
of the box. Depending on your application, some adjustments to the default settings may need to be
made.
Power Control and Battery Charging
To turn on your OSCOR unit, ensure that a charged battery is in the unit or connect the supplied AC
adapter and press the power button (see page 2). During operation, to turn off your OSCOR unit, press
and release the power button or select the Shutdown icon from the System Sub-Menu.
Press and hold the power button until the unit shuts off to perform a firmware reset. This method
should only be used if the unit has locked up and the normal shutdown methods are not functioning.
The OSCOR unit has a built in battery charger. To charge the battery, simply plug the supplied AC
adaptor into the unit with the battery in the OSCOR unit. Expected charge time is 1.5 hours; expected
run time is 3 hours.
Note: It is recommended that the OSCOR battery be recharged on a regular basis during extended
periods of storage (3 months or more) to prevent damage to the battery. Additionally, when storing the
OSCOR for long periods (1 month or more), it is recommended that the battery be removed from the
unit and placed in the storage compartment in the case. Storing the OSCOR with the battery in the unit
can deplete it more rapidly, potentially shortening the life of the battery.
Updating the Software and Firmware
Software updates, provided in the form of an .O2update file, will be made available by contacting REI
at sales@reiusa.net
. To update your OSCOR unit:
1. Place the downloaded .O2update file on a USB thumb drive or Compact Flash card and connect
the media to the OSCOR unit.
2. From the Main Menu, select System or press F6.
