Ricoh Aficio MP C2030 Service Manual

Punch Unit (D390)
SM 2-59 D037/D038/D040/D041
Installaion
d390i551
d390i550
[A]
Correct Incorrect
Push the slide plate [A] to check if the output tray lower cover is correctly installed. The
left side picture shows the correct result and the right side picture shows the incorrect
result.
6. Attach the left frame cover [A] ( x 2).
7. Push the internal finisher in the mainframe.
8. Connect the I/F cable [B] of the finisher to the inlet of the mainframe.
