SC Tables
D037/D038/D040/D041 4-48 SM Appendix
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Front Fan error
The machine detects the fan lock signal (ON) consecutively 200 ms.
 Front fan damaged
 Disconnect or defective the harness
 Front fan overload
798 D
1. Check or replace the harness.
2. Replace the front fan.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Output tray motor error
 Output tray motor damaged
 Output tray motor overload
 Loose connection of the Output tray motor
 Defective output tray motor
799 D
Replace the output tray unit.
4.1.9 SC8XX: OVERALL SYSTEM
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
Energy saving I/O sub-system error
The energy saving I/O sub-system detects an error.
 Controller board defective
816
CTL
D
Replace the controller board.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
817 CTL Monitor Error
