Ricoh Aficio MP C2030 Service Manual

Drive Unit
D037/D038/D040/D041 4-76 SM
4. Paper feed motor: T1 [A] ( x 1,  x 2)
 The picture below shows how to remove the screw [B] of the paper feed motor
T1.
4.10.4 PAPER FEED MOTOR: T2
1. Rear cover  Section: Rear Cover)
2. Rear lower cover ( Section:Rear Lower Cover)
3. Paper feed motor: T2 [A] ( x 1,  x 2)
4.10.5 DRUM MOTOR: CMY
