Maintenance Tables
SM Appendix 3-1 D037/D038/D040/D041
Appendix:
Preventive
Maintenance
Tables
3. APPENDIX: PREVENTIVE MAINTENANCE
TABLES
3.1 MAINTENANCE TABLES
3.1.1 PREVENTIVE MAINTENANCE ITEMS
Chart: A4 (LT)/5%
Mode: 3 copies / original (prints/job)
Ratio 30%
Environment: Normal temperature and humidity
Yield may change depending on circumstances and print conditions.
Symbol keys: C: Clean, R: Replace, L: Lubricant, I: Inspect
Mainframe
Item 60K 150K 240K EM Remarks
Scanner
Reflector C Optics cloth
1st/2nd/3rd Mirrors C Optics cloth
Front and Rear Rails C Dry cloth
Exposure Glass C C Dry cloth; alcohol
ADF Exposure Glass C C Dry cloth; alcohol
APS Sensor C Dry cloth
PCDU
Drum Unit-K, C, M, Y R
PCDU Toner Collection Bottle R
ITB and PTR unit
To Next Page
