Paper Feed Unit (D425)
D037/D038/D040/D041 2-24 SM
2.5 PAPER FEED UNIT (D425)
2.5.1 COMPONENT CHECK
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Paper Feed Unit 1
2 Securing bracket 2
3 Screw (M4 x 10) 4
2.5.2 INSTALLATION PROCEDURE
 Turn off the main switch of the copier and unplug the power cord before you start
the installation procedure.
 You need two or more persons to lift the copier. The copier is highly unstable when
lifted by one person, and may cause human injury or property damage.
 Do not lift the copier with the paper feed unit installed. The handle and grips may
be damaged.
 The one-tray paper feed unit must be installed on the caster table (D448). Prepare
the caster table first before installing this unit.
To Next Page
