Paper Feed Unit (D425)
SM 2-25 D037/D038/D040/D041
Installaion
This installation procedure uses the following symbols:
: Screws
1. Remove all tape on the paper feed unit.
2. Remove the paper tray and remove all tapes and padding.
3. Put the paper tray unit on the caster table (D448).
For details about the installation of the caster table, see the Section:
"Caster Table (D488)"” installation procedure.
4. Grasp the handle [A] and grips [B] of the machine.
5. Lift the copier and install it on the paper feed unit [C].
Hold the handle and grips of the machine when you lift and move the machine.
