Overview
SM Appendix 2-1 D037/D038/D040/D041
Appendix:
Overview
2. APPENDIX: OVERVIEW
2.1 OVERVIEW
2.1.1 MECHANICAL COMPONENT LAYOUT
1. 2nd carriage
2. 1st carriage
3. Original length sensor
4. Lens
5. SBU
6. Inverter roller
16. Vertical transport roller 2
17. Feed roller: T1
18. Vertical transport roller 3
19. Tray 2
20. Tray 1
21. Laser unit
