Exterior Covers
D037/D038/D040/D041 4-18 SM
Remove the screw [B] of the lower cover when reinstalling the rear cover.
4.4.6 REAR LOWER COVER
1. Rear lower cover [A] ( x 5)
4.4.7 DUST FILTER
1. Dust filter cover [A] (hooks)
2. Dust filter [B]
4.4.8 RIGHT REAR COVER
1. Rear cover ( Section: Rear Cover)
