Bit Switches
SM 73 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
document received. (When A5 is used to
print an A4 size document, for example.)
1
Repetition of data when the
received page is longer than
the printer paper
0: Off
1: On
1: Default. 10 mm of the trailing edge of the
previous page are repeated at the top of the next
page.
0: The next page continues from where the
previous page stopped without any repeated text.
2
Prints the date and time on
received fax messages
0: Disabled
1: Enabled
This switch is only effective when user parameter
02 - bit 2 (printing the received date and time on
received fax messages) is enabled.
1: The machine prints the received and printed
date and time at the bottom of each received
page.
3-7
Not used
Do not change the settings.
Printer Switch 01 [SP No. 1-103-002]
No FUNCTION COMMENTS
0-2
Not used
Do not change the settings.
3-4
Maximum print width used in
the setup protocol
Bit 4: 0, Bit 3: 0 = Not used
Bit 4: 0, Bit 3: 1 = A3
Bit 4: 1, Bit 3: 0 = B4
Bit 4: 1, Bit 3: 1 = A4
These bits are only effective when bit 7 of printer
switch 01 is “1”.
5-6
Not used
Do not change the settings.
7
Received message width
restriction in the protocol
signal to the sender
0: Disabled
1: Enabled
0: The machine informs the transmitting machine
of the print width depending on the paper size
available from the paper feed stations.
Refer to the table on the next page for how the
machine chooses the paper width used in the
setup protocol (NSF/DIS).
To Next Page
