Bit Switches
SM 75 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
1: Incoming page length is reduced when printing.
(Maximum reducible length: Printer Switches 04,
bits 0 to 4)
1-3 Not used Do not change the settings
4-7
Page separation setting when
sub scan compression is
forbidden
00-0F (0-15 mm: Hex)
Default: 6 mm
Page separation threshold (with reduction
disabled with switch 03-0 above).
For example, if this setting is set to "10", and A4 is
the selected paper size:
If the received document is 10 mm or less longer
than A4, then the 10 mm are cut and only 1 page
prints.
If the received document is 10 mm longer than A4,
then the document is split into 2 pages.
Printer Switch 04
SP No. 1-103-005
No FUNCTION COMMENTS
Maximum reducible length when length reduction is enabled with switch 03-0
above.
<Maximum reducible length> = <Paper length> + (N x 5mm)
“N” is the decimal value of the binary setting of bits 0 to 4.
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Setting
0 0 0 0 0 0 mm
0 0 0 0 1 5 mm
0 0 1 0 0 20 mm
1 1 1 1 1 155 mm
0-4
For A5 sideways and B5 sideways paper
<Maximum reducible length> = <Paper length> + 0.75 x (N x 5mm)
5-6 Length of the duplicated image on the next page, when page separation has taken
