Bit Switches
SM 101 D432/D433
D432/D433
Fax Option
Type
C2550/C2530
Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 1 2400 bps
0 0 1 1 4800 bps
0 0 1 1 7200 bps
0 1 0 0 9600 bps
0 1 0 1 12.0 Kbps
0 1 1 0 14.4 Kbps
4-5
Modem setting for transmission
Sets the modem for transmission.
The default is "00" (V29).
Bit 5: 0, Bit 4: 0 = V29
Bit 5: 0, Bit 4: 1 = V17
Bit 5: 1, Bit 4: 0 = V34*
Bit 5: 1, Bit 4: 1 = Not used
*V34 is not supported for IP-Fax communication.
6-7
Not used
Do not change these settings.
IP Fax Switch 06 [SP No. 1-111-007]
No. FUNCTION COMMENTS
Modem bit rate setting for reception
Sets the modem bit rate for reception. The default is "0110" (14.4K bps).
Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 1 2400 bps
0 0 1 0 4800 bps
0 0 1 1 7200 bps
0-3
0 1 0 0 9600 bps
