SD Card Appli Move
D037/D038/D040/D041 5-24 SM
during a firmware upgrade or application merge.
1. Turn the main switch off.
2. Insert the original SD card in SD Card Slot 2. The application program is copied back
into this card.
3. Insert the SD card (having stored the application program) to SD Card Slot 1. The
application program is copied back from this SD card.
4. Turn the main switch on.
5. Start the SP mode.
6. Select SP5-873-002 “Undo Exec.”
7. Follow the messages shown on the operation panel.
8. Turn the main switch off.
9. Remove the SD card from SD Card Slot 2.
This step assumes that the application programs in the SD card are used by
the machine.
10. Turn the main switch on.
11. Check that the application programs run normally.
