SC Tables
D037/D038/D040/D041 4-12 SM Appendix
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE OFF error: M
 The PFGATE ON signal still asserts within 5 seconds after
processing the image in normal job or MUSIC (line position
adjustment) for end position [M].
 The PFGATE ON signal still asserts when the next job starts.
235 D
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE ON error: C
The PFGATE ON signal does not assert within 5 seconds after
processing the image in normal job or MUSIC (line position adjustment)
for start position [C].
236 D
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
FGATE OFF error: C
 The PFGATE ON signal still asserts within 5 seconds after
processing the image in normal job or MUSIC (line position
adjustment) for end position [C].
 The PFGATE ON signal still asserts when the next job starts.
237 D
See SC 230 for troubleshooting details.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
240 C LD error: K
241 C LD error: Y
- -
The BCU detects LDB error a few times consecutively when LDB unit
To Next Page
