Ricoh Aficio MP C2030 Service Manual

Electrical Component Defects
D037/D038/D040/D041 8-4 SM Appendix
No.
Sensor Name/
Sensor Board Name
Active CN Condition Symptom
Shorted Jam C (Jam59)
Open
Used toner near full
indicated when it is not
near full.
Sxx
PCDU Toner
Collection Bottle Full
Sensor
H CN211/9
Shorted
Used toner near full
cannot be detected
when the waste toner
bottle is nearly full.
Open
Toner collection bottle
is not detected when
the waste toner bottle is
set.
SWx
PCDU Toner
Collection Bottle Set
Switch
L CN211/7
Shorted
Toner collection bottle
is detected when the
waste toner bottle is not
set.
Open
Used toner near full
indicated when it is not
near full.
Sxx
ITB Toner Collection
Bottle Full Sensor
H CN211/4
Shorted
Used toner near full
cannot be detected
when the waste toner
bottle is nearly full.
SWx
Tray 2 Paper Size
Switch
L
CN211/16,
17, 18, 20
Open/
Shorted
Paper size error
Sx
Temperature/
Humidity Sensor
A
CN222/15,
17
Open/
Shorted
Printed image has
some problems such as
rough image, dirty
background, weak
