System Service Mode
D037/D038/D040/D041 9-22 SM Appendix
029 R-Tray Exit Motor *ENG
[–2 to 2 / 0 / 0.05 %/step]
030 Fine Adj. Control *ENG
[0 to 1 / 1 /1]
031 Offset:120:Color *ENG
032 Offset:60:Color *ENG
[-7 to 7 / 0 /1step]
033 Regist Mot:60:1200dpi *ENG
[–4 to 4 / 0.3 / 0.05 %/step]
034 Feed1:CW60:1200dpi *ENG
035 Feed1:CCW60:1200dpi *ENG
036 Feed12:CW60:1200dpi *ENG
037 Feed12:CCW60:1200dpi *ENG
038 By-pass:60:1200dpi *ENG
[–2 to 2 / 0.3 / 0.05 %/step]
039 Reverse:CW60:1200dpi *ENG
040 Reverse:CCW60:1200dpi *ENG
[–2 to 2 / 0 / 0.05 %/step]
041 Fusing:Thin Nrml Mid *ENG
[–6 to 6 / -0.05 / 0.01 %/step]
042 BkOpcDevMot:60:1200dpi *ENG
[–4 to 4 / -0.4 / 0.01 %/step]
043 TransferMot:60:1200dpi *ENG
[–4 to 4 / 0 / 0.01 %/step]
1802 [CPM Setting]
001 - *ENG
[0 to 255 / 0 / 1 /step]
1803 [Sub Mag ADJ]
001 Plain:600dpi:input *ENG
002 Plain:1200dpi:input *ENG
003 Thick:input *ENG
[-1 to 1 / 0 / 0.1 %/step]
004 Plain:600dpi:result *ENG
[0 to 1 / 0 / 1 /step]
