System Service Mode
D037/D038/D040/D041 9-184 SM Appendix
Bit1: ORION register
Bit2: LUPUS register
Bit3 to 11: Not used
Bit12: Ri20
Bit13 to 15: Not used
0: OK, 1: Error
Performs a write and read check of the ASICs on the BCU board and displays
the result.
Test2 -
Bit0: Image path from SBU to TAURUS
Bit1: Image path from TAURUS to ORION
Bit2: Image path from ORION to TAURUS
Bit3: Image path from TAURUS to LUPUS
Bit4 to 11: Not used
Bit12: Image path from LUPUS to Ri20
Bit13: Image path from Ri20 to GAVD
Bit14 and 15: Not used
0: OK, 1: Error
002
Performs an image path check on the BCU board and displays the result.
[Dither Selection] DFU
4905
Changes the parameters for error diffusion.
001 Dither Selection *ENG
[0 to 255 / 0 / 1 /step] DFU
4909 [Man Gamma:Photo:Mono Bk] DFU
4910 [Man Gamma:Text:Bk]
4911 [Man Gamma:Text:C]
4912 [Man Gamma:Text:M]
4913 [Man Gamma:Text:Y]
001 Offset:Highlight *ENG
[0 to 30 / 15 / 1 /step]
