System Service Mode
D037/D038/D040/D041 9-342 SM Appendix
6120 3 Staple HP Sensor Not HP HP
6120 4 Paper T-Edge Sensor Paper not detected Paper detected
6120 5 Pick Roller Lift Sensor Up Down
6120 6 Paper Detection Sensor Paper not detected Paper detected
6120 7 Belt Roller Lift Sensor Down Up
6120 8 Entrance Sensor Paper not detected Paper detected
6120 9 Rear Jogger HP Sensor HP Not HP
6120 10 Front Jogger HP Sensor HP Not HP
6120 11 Fan Lock Signal Normal Lock
6120 12 Finisher Open Switch Close Open
6120 13 Punch Unit:Area Detect2
6120 14 Punch Unit:Area Detect1
See "Table 5" below.
6120 15 Paper Stack Sensor 2 HP Not HP
6120 16 Paper Stack Sensor 1 HP Not HP
6120 17 Punch Position Sensor Not HP HP
6120 18 Paper Width Sensor:A3 Paper not detected Paper detected
6120 19 Paper Width Sensor:LD Paper not detected Paper detected
6120 20 Paper Width Sensor:B4 Paper not detected Paper detected
6120 21 Paper Width Sensor:A4 Paper not detected Paper detected
6120 22 Paper Width Sensor:16K Paper not detected Paper detected
6120 23 Paper Width Sensor:B5 Paper not detected Paper detected
6120 24 Punch Hopper Full Sensor Full Not full
6120 25 Tray Upper Sensor Upper Not upper
