System Service Mode
D037/D038/D040/D041 9-344 SM Appendix
*1: The machine detects either 11" x 17" SEF or A3 SEF, depending on the setting of SP
5-181-002 (Tray 1) or SP 5-181-006 (Tray 2).
*2: The machine detects either 8.5" x 14" SEF or B4 SEF, depending on the setting of SP
5-181-003 (Tray 1) or SP 5-181-007 (Tray 2).
*3: The machine detects either 11" x 81/2" LEF or A4 LEF, depending on the setting of SP
5-181-001 (Tray 1) or SP 5-181-005 (Tray 2).
*4: The machine detects either B5 LEF or 10.5" x 7.25" LEF, depending on the setting of
SP 5-181-004 (Tray 1) or SP 5-181-008 (Tray 2).
Table 2: Paper Size (By-pass Table)
0: ON, 1: OFF
By-pass Paper Size Sensor
bit3 Bit2 Bit1 Bit0
Length
Sensor
NA EU/ASIA
1 1 0 0 0 HLT SEF B6 SEF
1 1 1 1 0 HLT SEF A5 SEF
1 1 1 0 0 HLT SEF A5 SEF
0 0 1 1 1 LT/LG SEF*
1
A4 SEF
0 0 1 1 0 LT/LG SEF*
1
A5 LEF
1 0 0 1 1 DLT SEF A3 SEF
1 0 0 1 0 LT LEF A4 LEF
*1: The paper size (LT or LG) can be selected with SP1-007-001.
Table 3: APS Original Size Detection
Original Size Width Sensor
Length
Sensor
Metric version
Inch
version
W1 W2 W3 L1 L2
SP4-301
display
