Using the Fax Function
186
6
Deleting individual destinations or groups
This section describes how to delete individual destinations or groups from the
LAN-Fax Address Book.
A Open the LAN-Fax Address Book, select the destination you want to delete
from [User List], and then click [Delete].
A confirmation message appears.
B Click [Yes].
Note
A destination is automatically deleted from a group if that destination is
deleted from the LAN-Fax Address Book. If you are deleting the last des-
tination from a group, a message asking you to confirm the deletion ap-
pears. Click [OK] if you want to delete the group.
Deleting a group does not delete the destinations it contains from the
LAN-Fax Address Book.
Exporting/Importing LAN-Fax Address Book data
This section describes how to export or import LAN-Fax Address Book data.
Exporting LAN-Fax Address Book data
LAN-Fax Address Book data can be exported to a file in CSV (Comma Sepa-
rated Values) format.
Importing LAN-Fax Address Book data
LAN-Fax Address Book data can be imported from files in CSV format. You
can import address book data from other applications if the data is saved as
a CSV file.
Exporting LAN-Fax Address Book data
Follow this procedure to export LAN-Fax Address Book data.
A Open the LAN-Fax Address Book, and then click [Export].
B Navigate to the location to save the LAN-Fax Address Book data, specify a
name for the file, and then click [Save].
Importing LAN-Fax Address Book data
Follow this procedure to import LAN-Fax Address Book data. To import ad-
dress book data from other applications, you must select the appropriate items
to import.
A Open the LAN-Fax Address Book, and then click [Import].

Table of Contents

Other manuals for Ricoh Aficio SP 3400SF

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Ricoh Aficio SP 3400SF and is the answer not in the manual?

Ricoh Aficio SP 3400SF Specifications

Aficio SP 3400SF

Power IconPower
power source120V, 60 Hz
Printer Specifications IconPrinter Specifications
print/copy speed30 ppm/cpm
resolution600 x 600 dpi, 1200 x 600 dpi
print featuresLocked Print (PCL 6), Collate, Layout (N-up), Front Cover Sheet, Letterhead Mode, Mirror Image Print (PS3), Dithering, Toner Saving, Watermark, Rotate Print, Reverse Order Print (PS3)
Copier Specifications IconCopier Specifications
first copy speedPlaten: 12 seconds/ADF: 11 seconds
multi-copy speed20 copies-per-minute
output resolution600 x 600 dpi
Scanner Specifications IconScanner Specifications
scanner resolution1200 x1200 dpi; Driver: Max. 19200 x 19200 dpi (interpolated)
max. original sizePlaten: Width up to 8.5", length up to 11.69"; ADF: Width up to 8.5", length up to 14"
scan modesADF & Platen: Black & white, grayscale, color
Facsimile Specifications IconFacsimile Specifications
modem speed33.6 Kbps
resolution200 x 100 dpi, 200 x 200 dpi
transmission speedApprox. 3 seconds
Weight and Dimensions IconWeight and Dimensions
dimensions16.5" x 15.6" x 17.4"
weightLess than 39.7 lbs. (18 kg)

Aficio SP 3410SF

Power IconPower
power source120V, 60 Hz
Printer Specifications IconPrinter Specifications
print/copy speed30 ppm/cpm
resolution600 x 600 dpi, 1200 x 600 dpi
print featuresLocked Print (PCL 6), Collate, Layout (N-up), Front Cover Sheet, Letterhead Mode, Mirror Image Print (PS3), Dithering, Toner Saving, Watermark, Rotate Print, Reverse Order Print (PS3)
Copier Specifications IconCopier Specifications
first copy speedPlaten: 12 seconds/ADF: 11 seconds
multi-copy speed20 copies-per-minute
output resolution600 x 600 dpi
Scanner Specifications IconScanner Specifications
scanner resolution1200 x1200 dpi; Driver: Max. 19200 x 19200 dpi (interpolated)
max. original sizePlaten: Width up to 8.5", length up to 11.69"; ADF: Width up to 8.5", length up to 14"
scan modesADF & Platen: Black & white, grayscale, color
Facsimile Specifications IconFacsimile Specifications
modem speed33.6 Kbps
resolution200 x 100 dpi, 200 x 200 dpi
transmission speedApprox. 3 seconds
Weight and Dimensions IconWeight and Dimensions
dimensions16.5" x 15.6" x 17.4"
weightLess than 39.7 lbs. (18 kg)
