Scanning Using the Control Panel
145
5
Basic Operation for Scan to USB
This section describes the basic operation for sending scanned files to a USB
flash disk.
Important
❒ The original in the ADF takes precedence over the original on the exposure
glass if you place originals both in the ADF and on the exposure glass.
❒ This machine does not support the use of USB flash disks connected to exter-
nal USB hubs. Insert your USB flash disk directly into the USB flash disk port
located at the top left corner of the machine.
❒ Certain types of USB flash disks cannot be used.
A Insert your USB flash disk into the USB flash disk port.
B Press the {Scanner} key.
"Loading..." appears on the display. Wait until the display changes to show
the following screen (the duration depends on your USB flash disk).
"Color" or "GrayScale" may appear instead of "Mono", depending on the ma-
chine's scanning mode.
BSP194S
BSP044S
Ready Mono
To USB Memory
