1-Bin Tray Unit (D367)
D017/D018/D019/D020/D084/D085 2-31 SM
Installation
2.7 1-BIN TRAY UNIT (D367)
2.7.1 COMPONENT CHECK
Check the quantity and condition of the components against the following list.
No. Description Qty
1 1-Bin Tray Guide 1
2 1 Bin Tray Unit 1
3 Tapping Screw M3 x 8 1
4 Sub-tray 1
5 Tray Guide 1
6 Tray 1
