Duplex Unit (D369)
D017/D018/D019/D020/D084/D085 2-41 SM
Installation
2.10 DUPLEX UNIT (D369)
2.10.1 ACCESSORY CHECK
Check the quantity and condition of the components against the following list.
No. Description Quantity
1 Duplex Unit 1
2 Connector Cover 1
3 Tapping Screw - M3x8 1
4 Clip 1
5 Tapping Screw - M3x6 1
6 Duplex Guide 1
7 Duplex Tray 1
8 Duplex Tray Guide 1
9 Link Bracket 1
