Ricoh SP 330DN Service Manual

Maintenance Mode (for Touch Panel Models)
M0C3/M0C4/M0C5/M0C6/M0C7 5-20 SM
Menu Description
[On or Off (Default)]
With the main motor rotation count feature, the machine can be
set to stop printing after the print total exceeds a certain set
value. If the print count exceeds this value, then "Replace Print
Cartridge" remains in the display. Then a new AIO cartridge
must be installed. This feature is a safety measure to prevent the
used toner tank from becoming full (there is no toner overflow
detection mechanism).
Test Pattern Prints the test pattern.
1200dpi LD Power
Adjusts print density (density levels by increasing the number)
[42 to 106 / 74 (Default) / 1 /step]
Refill mode setting
DFU
[Auto refill mode/ Pure refill mode]
OPC Life Info OPC
Rotation
Time
Displays the OPC life information (OPC rotation time).
Pre-OPC
Rotation
Time
Displays the OPC life information (Pre-OPC rotation time)
OPC Alert
Status
Displays the OPC life information (Alert status)
OPC
Pre-Alert
Status
Displays the OPC life information (Pre-Alert status)
Subscan Magnification
Adjusts the sub scan magnification.
[-8 to 8 / 0 / 1/step]
Page Dot
Coverage
0%-2% Displays the number of pages printed with coverage 0 to 2%.
3%-4% Displays the number of pages printed with coverage 3 to 4%.
5%-7% Displays the number of pages printed with coverage 5 to 7%.
8%-9% Displays the number of pages printed with coverage 8 to 9%.
10%-19% Displays the number of pages printed with coverage 10 to 19%.
20%-29% Displays the number of pages printed with coverage 20 to 29%.
Above 30% Displays the number of pages printed with coverage above 30%.
Power On Count Displays the power on counter.
Sleep Recover Count Displays the sleep recover counter.
Machine Series Number
DFU

Ricoh SP 330DN Specifications

General

Print technology	Laser
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	7.5 s
Print speed (black, normal quality, A4/US Letter)	32 ppm
Printing colors	Black, White
Maximum duty cycle	- pages per month
Number of print cartridges	1
Page description languages	PCL 5e, PCL 6, PostScript 3
Multi-Purpose tray	Yes
Total input capacity	550 sheets
Total output capacity	125 sheets
Paper tray media types	-
Paper tray media weight	52 - 162 g/m²
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5, B6
Maximum ISO A-series paper size	A4
USB connector	USB Type-B
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Sound pressure level (printing)	- dB
Market positioning	Home & office
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.72 W
Energy Star Typical Electricity Consumption (TEC)	0.41 kWh/week
Mac operating systems supported	Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.15.3 Catalina, Mac OS X 11.0 Big Sur
Server operating systems supported	Windows Server 2008, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016
Windows operating systems supported	Windows 10, Windows 7, Windows 8.1

Weight and Dimensions

Depth	392 mm
Width	370 mm
Height	262 mm
