4.Replacement and Adjustment
56
cover, see the photos below.
ARDF Rear Cover
1. Remove the ARDF unit (ARDF Unit).
2. Turn the ARDF unit over.
3. Remove the ARDF rear cover [A].
There are many hooks and tabs inside the ARDF rear cover. Before removing the ARDF rear
