3.3 SERVICE TOOLS
S6 PCB Layout
The attribute of the PCB layout can be read and set.
The attribute (e.g. c) is shown on the right upper corner
of the window.
Software applications may be depend on this attribute.
The attribute is labelled on the PCB RR_120 near plug
ST13.
The attribute can be changed with [SELECT].
The input has to be confirmed with [OK].
[EXIT] leaves the function without any changes.
PCB LAYOUT c
EXIT OK SELECT
S7 Set Wavelength
The assignment of wavelength and filter position can
be done.
The current filter position is blinking.
With [SELECT] the filter position can be set.
With [NEW] the wavelength can be edited.
[EXIT] leaves the function without any changes.
In the first line the current filter position is shown.
The new value of the wavelength has to be entered.
The input has to be confirmed with [E].
SET WAVELENGTH
1: 340 6: 623
2: 405 7: 999
3: 492 8: 999
4: 546 9: 999
5: 578
EXIT NEW SELECT
NEW WAVELENGTH 1
1 2 3 4 5 6 7 8
ESC 9 0 . + - E
RIELE BERLIN Photometer 5010 V5+ 3.3.7 11.03.2009
