Riele Photometer 5010 V5+ - Metal Tube Inlet

4.32 METAL TUBE INLET REF 5010-055
Function Description
The metal tube inlet is used to guide the aspirate
tubing.
Metal tube inlet
Location
Top case
Replacement
Remove aspirate tubing from metal tube inlet.
Remove metal tube inlet by turning and pulling at the same time.
Installation
For installation proceed in reverse order.
RIELE BERLIN Photometer 5010 V5+ 4.32.1 15.05.2006
