3.3 SERVICE TOOLS
S12 Temperature Calibration
The correction of the temperature regulation is possible
by input of the temperature value which is measured in
the cuvette with an external measuring system
(Thermistor and DMM).
This function is available only when the temperature
regulation is stabilized. In an unstable condition an
error message is shown on the display.
Enter the actual temperature value always four-digit in
° C e.g. [3] [7] [.] [2] [0] measured by an external
measuring system.
Confirm with [E].
The system calculates and stores the new setting for
the selected temperature level and starts working with it
at once.
TEMP. CALIBRATION
TEMP. ACTUAL :
1 2 3 4 5 6 7 8
ESC 9 0 . + - E
S13 ADC Correction
The current ADC correction of the device can be read
and set.
The range of this value is 0 up to 255. The default
value is 150.
The input has to be confirmed with [E].
ADC CORRECTION 150
1 2 3 4 5 6 7 8
ESC 9 0 . + - E
S14 ADC Counts (Optic)
Indicated is the current value of the optical analogue-
digital converter. The value is proportional to the light-
current depending on the selected amplification level
and the boost setting.
To a key actuation the system reacts possibly only after
three seconds.
The functions V0 to V7 set the amplification level. The
function BO increases (boost ON) or reduces (boost
OFF) the time slot. The functions F0 to F9 place the
filter wheel into the positions 0 to 9. The position 0
corresponds to the filter wheel position at the dark level
adjustment.
Stop function by [ESC].
ADC COUNTS (OPTIC)
BOOST OFF
V0 F1 340nm 18810
V0 V1 V2 V3 V4 V5 V6 V7 B0.
F0 F1 F2 F3 F4 F5 F6 F7 F8 F9
ESC
RIELE BERLIN Photometer 5010 V5+ 3.3.10 11.03.2009
