4.40 PCB RR-120 MOTHERBOARD REF 5010-120
Installation instruction
In case of changing the mother board following items have to be done after switching on the device:
1. Check the contrast of LCD
(Service Manual chapter 4.42 – Contrast of touchscreen).
2. Check the voltage 12 V
DC
of halogen lamp. The voltage was pre-adjusted at the factory
(Service Manual chapter 4.40 – Voltage 12 V
DC
of halogen lamp).
3. Check voltages + 12 V
DC
, - 12 V
DC
, + 5 V
DC
and + 3 V
DC
(battery power)
(Service Manual chapter 4.40 – Voltages).
4. Perform the adjustment of amplifier stage
(Service Manual chapter 4.40 – Adjustment of amplifier stage).
5. The display of Photometer 5010 V5+ shows:
MAIN MENU
MEASURE WITH PROGR. METHODS
MEASURE WITH BASIC METHODS
METHODS NEW / CHANGE / COPY
UTILITIES LAMP LF
37.05C 04.01.06 11:39
6. The serial number can be set by applying the service tool S5
(Service Manual chapter 3.3 – S5 - Serial no.).
7. The assignment of filter positions has to be done if additional filters has been built in
(e.g. 670 nm). Apply the service tool S7
(Service Manual chapter 3.3 – S7 – Set wavelength).
8. Do a setting of the temperature values by performing the calibration procedure of
Photometer 5010 V5+.
(Service Manual chapter 9.1 - Subject: Cuvette temperature)
(Service Manual chapter 4.40 - Thermal adjustment)
9. Do a setting of “attribute of PCB layout“ by applying the service tool S6:
Software applications may be dependent on this attribute
(Service Manual chapter 3.3 – S6 - PCB layout).
10. Delete allocated memory by applying the service tool S2:
(Service Manual chapter 3.3 – S2.1 – Delete free methods)
(Service Manual chapter 3.3 – S2.2 – Multi-standard memory)
(Service Manual chapter 3.3 – S2.3 – Delete logger memory)
(Service Manual chapter 3.3 – S2.4 – Delete QC memory)
11. Define the laboratory name by applying the utility U11:
The name of the laboratory can be stored permanently
(OM chapter 7.2.11 – Laboratory name).
12. Define the user names by applying the utility U12:
The names of maximum five users can be stored permanently
(OM chapter 7.2.12 – User name).
13. Do a dark level adjustment by applying utility U1 in combination with flow-through system.
(OM chapter 7.2.1 - Dark level adjustment).
The utility is working specifically to the current adaptor. An adjustment of the standard cuvette adaptor
should be done later on.
14. Perform a media test by applying utility U4.4
(OM chapter 7.2.4.2 – Media test).
RIELE BERLIN Photometer 5010 V5+ 4.40.12 17.03.2009
