4.22 STANDARD CUVETTE ADAPTOR REF 1704800001
Function Description
The standard cuvette adaptor is used for disposable cuvettes or for working with a discrete flow-through cell.
The standard cuvette adaptor consists of:
• Plastic adapter
• Heating unit
• Plug
• Potentiometer for factory calibration
Location
Optical unit
Replacement
Loosen clamp screw, remove adaptor.
Installation
For installation proceed in reverse order.
After installation of a new cuvette adaptor a dark level adjustment has to be done by
[UTILITIES] [DARK LEVEL ADJUSTMENT] [START].
Holding spring for disp. cuvette
REF 1707159001
RIELE BERLIN Photometer 5010 V5+ 4.22.1 28.04.2006
