3.3 SERVICE TOOLS
S19 Automatic Results
This operation works only with standard cuvette
adapter!
The function invokes by [START] a test based on the
calculation procedure 1 ↔ C/F (OM chapter 5.4.1).
For each setting parameter a leading identification
number is shown. If the identification number is
selected on the keyboard, the corresponding setting
parameter becomes configurable.
After setting parameters like wavelength, factor, delay
time, unit, … the procedure is started by [OK].
By setting delay time the intervals between the
measurements can be defined.
The procedure is working in an open loop and
produces results as long as the [EXIT] is pushed.
By [ZERO] an automatic zero adjustment can be done.
To a key actuation the system reacts possibly only after
three seconds.
AUTOMATIC RESULTS
EXIT START
METHOD NO. 1 C/F
1-WAVELENGTH 340nm
2-FACTOR 1.000 EXIT
3-TEMPERATURE 37C
4-DELAY 0s
5-UNIT OK
6-
7-
8-
1 2 3 4 5 6 7 8 P1/3
DELAY 5 C/F
42
EXIT MODE WASH ZERO RESULT
1.234
S20 BCC of Method/Curve
To check the correct storing of a user-defined method
or curve, the special test byte BCC concerning the data
in the memory is used. With this service program the
BCC of a method can be determined.
With [M] the BCC of a method can be tested.
With [C] the BCC of a curve can be tested.
BCC OF METHOD/CURVE
EXIT M C
RIELE BERLIN Photometer 5010 V5+ 3.3.13 11.03.2009
