4.1 MAINS POWER CIRCUIT
power input
90 V~ - 264 V~
gnye gnye
fuses Fa and Fb
ground
connection
wh gr
mains switch
br bk
line filter
br bk
PE N L
AC / DC
power supply
REF 5010-016
(terminal block
with 7-pins)
RIELE BERLIN Photometer 5010 V5+ 4.1.2 18.08.2010
