Riele Photometer 5010 V5+ - 4.12 HALOGEN LAMP

4.12 HALOGEN LAMP REF 0554871001
RIELE BERLIN Photometer 5010 V5+ 4.12.1 12.05.2007
Function Description
The halogen lamp is working with 12 V
DC
and an
electrical power of 20 W.
Location
Optical unit
The Photometer 5010 V5+ has to be dismantled
(see chapter 5.1 – Opening – item 3 and item 5).
Unscrew the cylinder head screw.
Remove the lamp shield.
Replacement
Unscrew the knurled head screw.
Remove the holding plate.
