4.35 PRINTER MECHANISM 8NAD REF 5010-052
Installation
For installation proceed in reverse order.
Marked lead
Solder printer connection cable to printer mechanism.
Also take care for marked lead of pin 1.
RIELE BERLIN Photometer 5010 V5+ 4.35.2 15.05.2006
