Rigol DS1054Z Programming Guide

RIGOL Chapter 2 Command System
2-204 MSO1000Z/DS1000Z Programming Guide
:TRIGger:RS232:BAUD
Syntax
:TRIGger:RS232:BAUD <baud_rate>
:TRIGger:RS232:BAUD?
Description
Set or query the baud rate in RS232 trigger. The default unit is bps.
Parameter
Name
Type
Range
Default
<baud_rate>
Discrete
{2400|4800|9600|19200|38400|57600|
115200|230400|460800|921600|1000000|
USER}
9600
Return Format
The query returns an integer or USER.
Example
:TRIGger:RS232:BAUD 4800 /*Set the baud rate to 4800bps*/
:TRIGger:RS232:BAUD? /*The query returns 4800*/
Related
Command
:TRIGger:RS232:BUSer
:TRIGger:RS232:BUSer
Syntax
:TRIGger:RS232:BUSer <user baud>
:TRIGger:RS232:BUSer?
Description
Set or query the user-defined baud rate in RS232 trigger. The default unit is bps.
Parameter
Name
Type
Range
Default
<user baud>
Integer
110 to 20000000
9600
Return Format
The query returns an integer.
Example
:TRIGger:RS232:BUSer 50000 /*Set the user-defined baud rate to 50000bps*/
:TRIGger:RS232:BUSer? /*The query returns 50000*/
Related
Command
:TRIGger:RS232:BAUD

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
