Rigol DS1054Z Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-51
:DECoder<n>:SPI:MISO
Syntax
:DECoder<n>:SPI:MISO <miso>
:DECoder<n>:SPI:MISO?
Description
Set or query the MISO channel source in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<miso>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
OFF
Explanation
When OFF is selected, no MISO channel source will be set. The MISO channel source and
MOSI channel source (:DECoder<n>:SPI:MOSI) cannot be both set to OFF.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:DECoder1:SPI:MISO D0 /*Set the MISO channel source in SPI decoding to D0*/
:DECoder1:SPI:MISO? /*The query returns D0*/
:DECoder<n>:SPI:MOSI
Syntax
:DECoder<n>:SPI:MOSI <mosi>
:DECoder<n>:SPI:MOSI?
Description
Set or query the MOSI channel source in SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<mosi>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4|OFF}
CHANnel2
Explanation
When OFF is selected, no MOSI channel source will be set. The MOSI channel source and
MISO channel source (:DECoder<n>:SPI:MISO) cannot be both set to OFF.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, CHAN4, or OFF.
Example
:DECoder1:SPI:MOSI D1 /*Set the MOSI channel source in SPI decoding to D1*/
:DECoder1:SPI:MOSI? /*The query returns D1*/

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
