RIGOL Chapter 2 Command System
2-58 MSO1000Z/DS1000Z Programming Guide
:DECoder<n>:PARallel:BITX
Syntax
:DECoder<n>:PARallel:BITX <bit>
:DECoder<n>:PARallel:BITX?
Description
Set or query the data bit that requires a channel source on the parallel bus.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<bit>
Integer
0 to (data width - 1)
0
Explanation
 Set the data width using the :DECoder<n>:PARallel:WIDTh command.
 After selecting the desired bit, send the :DECoder<n>:PARallel:SOURce command to
set the channel source of this bit.
Return
Format
The query returns the current data bit in integer.
Example
:DECoder1:PARallel:BITX 2 /*Set the current bit to 2*/
:DECoder1:PARallel:BITX? /*The query returns 2*/
:DECoder<n>:PARallel:SOURce
Syntax
:DECoder<n>:PARallel:SOURce <src>
:DECoder<n>:PARallel:SOURce?
Description
Set ro query the channel source of the data bit currently selected.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<src>
Discrete
{D0|D1|D2|D3|D4|D5|D6|D7|D8|
D9|D10|D11|D12|D13|D14|D15|
CHANnel1|CHANnel2|CHANnel3|CHANnel4}
Related to
the bit
selected
Explanation
Before sending this command, use the :DECoder<n>:PARallel:BITX command to select
the desired data bit.
Return
Format
The query returns D0, D1, D2, D3, D4, D5, D6, D7, D8, D9, D10, D11, D12, D13, D14,
D15, CHAN1, CHAN2, CHAN3, or CHAN4.
Example
:DECoder1:PARallel:SOURce CHANnel2 /*Set the channel source of the current bit to
CH2*/
:DECoder1:PARallel:SOURce? /*The query returns CHAN2*/
Related
Command
:DECoder<n>:PARallel:WIDTh

Rigol DS1054Z Specifications

General

Channels	4
Bandwidth	50 MHz
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Display	7 inch TFT LCD (800x480)
Vertical Sensitivity	1 mV/div to 10 V/div
Time Base Range	5 ns/div to 50 s/div
Vertical Resolution	8 bits
Trigger Types	Edge, Pulse, Video, Slope
Connectivity	USB Host, USB Device, LAN
Input Impedance	1 MΩ
Power Supply	100-240 VAC, 45-440 Hz
