Rigol DS1104Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-174 MSO1000Z/DS1000Z Programming Guide
:TRIGger:VIDeo:MODE
Syntax
:TRIGger:VIDeo:MODE <mode>
:TRIGger:VIDeo:MODE?
Description
Set or query the sync type in video trigger.
Parameter
Name
Type
Range
Default
<mode>
Discrete
{ODDField|EVENfield|LINE|ALINes}
ALINes
Explanation
 ODDField: trigger on the rising edge of the first ramp waveform pulse in the odd
field. This type is available when the video standard is NTSC or PAL/SECAM.
 EVENfield: trigger on the rising edge of the first ramp waveform pulse in the even
field. This type is available when the video standard is NTSC or PAL/SECAM.
 LINE: for the NTSC and PAL/SECAM video standards, trigger on the specified line in
the odd or even field; for the 480P and 576P video standards, trigger on the specified
line.
 ALINes: trigger on all the horizontal sync pulses.
Return
Format
The query returns ODDF, EVEN, LINE, or ALIN.
Example
:TRIGger:VIDeo:MODE ODDField /*Set the sync type to odd field*/
:TRIGger:VIDeo:MODE? /*The query returns ODDF*/
Related
Commands
:TRIGger:VIDeo:LINE
:TRIGger:VIDeo:STANdard
:TRIGger:VIDeo:LINE
Syntax
:TRIGger:VIDeo:LINE <line>
:TRIGger:VIDeo:LINE?
Description
Set or query the line number when the sync type in video trigger is LINE.
Parameter
Name
Type
Range
Default
<line>
Integer
Refer to Explanation
1
Explanation
 NTSC: 1 to 525
 PAL/SECAM: 1 to 625
 480P: 1 to 525
 576P: 1 to 625
Return
Format
The query returns an integer.
Example
:TRIGger:VIDeo:LINE 100 /*Set the line number to 100*/
:TRIGger:VIDeo:LINE? /*The query returns 100*/
Related
Command
:TRIGger:VIDeo:MODE

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
