Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-181
:TRIGger:DURATion:WHEN
Syntax
:TRIGger:DURATion:WHEN <when>
:TRIGger:DURATion:WHEN?
Description
Set or query the trigger condition in duration trigger.
Parameter
Name
Type
Range
Default
<when>
Discrete
{GREater|LESS|GLESs}
GREater
Explanation
 GREater: you need to specify a time (refer to :TRIGger:DURATion:TLOWer). The
oscilloscope triggers when the duration of the pattern is greater than the preset time.
 LESS: you need to specify a time (refer to :TRIGger:DURATion:TUPPer). The
oscilloscope triggers when the duration of the pattern is lower than the preset time.
 GLESs: you need to specify an upper limit of the time (refer
to :TRIGger:DURATion:TUPPer) and lower limit of the time (refer
to :TRIGger:DURATion:TLOWer). The oscilloscope triggers when the duration of the
pattern is lower than the preset upper limit of the time and greater than the preset
lower limit of the time.
Return
Format
The query returns GRE, LESS, or GLES.
Example
:TRIGger:DURATion:WHEN LESS /*Set the trigger condition to <*/
:TRIGger:DURATion:WHEN? /*The query returns LESS*/
:TRIGger:DURATion:TUPPer
Syntax
:TRIGger:DURATion:TUPPer <NR3>
:TRIGger:DURATion:TUPPer?
Description
Set or query the duration time upper limit in duration trigger. The default unit is s.
Parameter
Name
Type
Range
Default
<NR3>
Real
Related to the trigger condition
LESS: 8ns to 10s
GLESs: 16ns to 10s
2μs
Explanation
This command is available when the trigger condition (:TRIGger:DURATion:WHEN) is
LESS or GLESs.
Return
Format
The query returns the duration time upper limit in scientific notation.
Example
:TRIGger:DURATion:TUPPer 0.000003 /*Set the duration time upper limit to 3μs*/
:TRIGger:DURATion:TUPPer? /*The query returns 3.000000e-06*/
Related
Command
:TRIGger:DURATion:TLOWer

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
