Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-27
:CURSor:TRACk:AXValue?
Syntax
:CURSor:TRACk:AXValue?
Description
Query the X value of cursor A in the track cursor measurement mode. The default unit is s.
Return
Format
The query returns the X value of cursor A in scientific notation.
Example
:CURSor:TRACk:AXValue? /*The query returns -4.000000e-06*/
Related
Command
:CURSor:TRACk:AX
:CURSor:TRACk:AYValue?
Syntax
:CURSor:TRACk:AYValue?
Description
Query the Y value of cursor A in the track cursor measurement mode. The unit is the same
as the channel unit currently selected.
Return
Format
The query returns the Y value of cursor A in scientific notation.
Example
:CURSor:TRACk:AYValue? /*The query returns -4.000000e-01*/
Related
Commands
:CHANnel<n>:UNITs
:CURSor:TRACk:AY?
:CURSor:TRACk:BXValue?
Syntax
:CURSor:TRACk:BXValue?
Description
Query the X value of cursor B in the track cursor measurement mode. The default unit is s.
Return
Format
The query returns the X value of cursor B in scientific notation.
Example
:CURSor:TRACk:BXValue? /*The query returns 4.000000e-06*/
Related
Command
:CURSor:TRACk:BX
:CURSor:TRACk:BYValue?
Syntax
:CURSor:TRACk:BYValue?
Description
Query the Y value of cursor B in the track cursor measurement mode. The unit is the same
as the channel unit currently selected.
Return
Format
The query returns the Y value of cursor B in scientific notation.
Example
:CURSor:TRACk:BYValue? /*The query returns 4.000000e-01*/
Related
Commands
:CHANnel<n>:UNITs
:CURSor:TRACk:BY?

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
