Rigol DS1104Z Plus Programming Guide

RIGOL Chapter 2 Command System
2-28 MSO1000Z/DS1000Z Programming Guide
:CURSor:TRACk:XDELta?
Syntax
:CURSor:TRACk:XDELta?
Description
Query the difference between the X values of cursor A and cursor B (BX-AX) in the track
cursor measurement mode. The default unit is s.
Return
Format
The query returns the difference in scientific notation.
Example
:CURSor:TRACk:XDELta? /*The query returns 8.000000e-06*/
Related
Commands
:CURSor:TRACk:AX
:CURSor:TRACk:BX
:CURSor:TRACk:YDELta?
Syntax
:CURSor:TRACk:YDELta?
Description
Query the difference between the Y values of cursor A and cursor B (BY-AY) in the track
cursor measurement mode. The unit is the same as the channel unit currently selected.
Return
Format
The query returns the difference in scientific notation.
Example
:CURSor:TRACk:YDELta? /*The query returns 8.000000e-01*/
Related
Commands
:CURSor:TRACk:AY?
:CURSor:TRACk:BY?
:CURSor:TRACk:IXDELTA?
Syntax
:CURSor:TRACk:IXDELTA?
Description
Query the reciprocal of the absolute value of the difference between the X values of cursor
A and cursor B (1/|dX|) in the track cursor measurement mode. The default unit is Hz.
Return
Format
The query returns 1/|dX| in scientific notation.
Example
:CURSor:TRACk:IXDELTA? /*The query returns 1.250000e+05*/
Related
Commands
:CURSor:TRACk:AX
:CURSor:TRACk:BX

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
