Rigol DS1104Z Plus Programming Guide

Chapter 2 Command System RIGOL
MSO1000Z/DS1000Z Programming Guide 2-53
:DECoder<n>:SPI:MODE
Syntax
:DECoder<n>:SPI:MODE <CsTmo>
:DECoder<n>:SPI:MODE?
Description
Set or query the frame synchronization mode of SPI decoding.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<CsTmo>
Discrete
{CS|TIMeout}
TIMeout
Explanation
 CS: it contains a chip select line (CS). You can perform frame synchronization
according to CS. At this point, you need to send the :DECoder<n>:SPI:CS
and :DECoder<n>:SPI:SELect commands to set the CS channel source and polarity.
 TIMeout: you can perform frame synchronization according to the timeout time. At
this point, you need to send the :DECoder<n>:SPI:TIMeout command to set the
timeout time.
Return
Format
The query returns CS or TIM.
Example
:DECoder1:SPI:MODE CS /*Set the frame synchronization mode of SPI decoding to
CS*/
:DECoder1:SPI:MODE? /*The query returns CS*/
:DECoder<n>:SPI:TIMeout
Syntax
:DECoder<n>:SPI:TIMeout <tmo>
:DECoder<n>:SPI:TIMeout?
Description
Set or query the timeout time in the timeout mode of SPI decoding. The default unit is s.
Parameter
Name
Type
Range
Default
<n>
Discrete
{1|2}
--
<tmo>
Real
Refer to Explanation
1.00us
Explanation
 The timeout time should be greater than the maximum pulse width of the clock and
lower than the idle time between frames.
 This command is only valid in the timeout mode (:DECoder<n>:SPI:MODE).
Return
Format
The query returns the timeout time in scientific notation.
Example
:DECoder1:SPI:TIMeout 0.000005 /*Set the timeout time to 5us*/
:DECoder1:SPI:TIMeout? /*The query returns 5.000000e-06*/

Rigol DS1104Z Plus Specifications

General

Bandwidth	100 MHz
Channels	4
Sample Rate	1 GSa/s
Memory Depth	24 Mpts
Waveform Capture Rate	30, 000 wfms/s
Vertical Sensitivity	1 mV/div to 10 V/div
Timebase Range	5 ns/div to 50 s/div
Connectivity	USB Host, USB Device, LAN, AUX
Vertical Resolution	8 bits
Power Supply	100-240 V AC, 45-440 Hz
Display	7 inch TFT LCD
Trigger Types	Edge, Pulse, Video, Slope
Input Impedance	1 MΩ ± 2%
