RIGOL Front Panel Key Reference
2-112 User’s Guide for DSA1000 Series
2.6.4.3 File Source
Sets the file source of the storage to T1, T2, T3, Math Trace or All. Note that this menu
is available only when the File Type is set to Trace and the storage in current use is
an external USB storage device.
2.6.4.4 Browser
Sets the browser type. You can switch among the directory or file by using the
direction keys or the knob.
2.6.4.5 Save
Saves a file into the external or internal memory. Note that the length of a filename is
limited to a maximum of 48 characters.
2.6.4.6 Expand Dir
Expands the directories.
2.6.4.7 Collapse Dir
Collapses the directories.
2.6.4.8 Recall
Reads the selected file and loads it into the system.
To Next Page
