Front Panel Key Reference RIGOL
User’s Guide for DSA1000 Series
2-113
2.6.4.9 Rename
Renames a stored file.
2.6.4.10 Copy
1. Copy From
Copies files or folders.
 When "Dir" is selected in Browser, pressing this key will copy all files or
folders in the current path.
 When "File" is selected in Browser, pressing this key will copy the selected
file or folder.
2. Copy To
Performs the paste operation of a directory or file.
Note: When the current directory already contains a file or folder with the same
name, a backup copy will be created with the prefix “Dup” after executing the
paste operation.
3. Browser
A shortcut key. Refer to “Browser”.
4. Expand Dir
A shortcut key. Refer to “Expand Dir”.
5. Collapse Dir
A shortcut key. Refer to “Collapse Dir”.
2.6.4.11 Create Dir
Creates a directory in the current path. Note that the length of a directory name is
limited to a maximum of 48 characters.
